Sony α6700 settings

Three years ago the Sony α6600 became part of my equipment, the first “mature” camera body of my system. Arguably that role could have been assigned to the α6300, but it lacks IBIS and, with Sony’s approach of not incorporating OSS in new lenses under 70mm, in-sensor stabilisation cannot be considered an optional any longer. The introduction of the α6600 phased out the NEX-6, that — while perfectly capable to take excellent photos in simple scenarios — was clearly too NAIVE for a serious amateur use. Paradoxically, the new low-entry, the α6000, sports an EVF that is very poor in comparison. This, together with the lack of IBIS and an AF system that sometimes, though rarely, misses the spot even with landscape shots, was the new problem to solve in my equipment.

Sony α6700 + Sony FE 200-600mm F5.6-6.3 G OSS @ 391 mm, 1/2000 sec @ ƒ/8, -1.00 EV, ISO 200

Gabbiano reale mediterraneo (Larus michahellis).

Being fine with the capability of the α6600 AF to track animals in motion, my desire was for an inexpensive, simple body for landscapes only: without leading edge technology and as light as possible (the combination of α6000 together with the Samyang 35mm F2.8 was so incredibly compact and LIGHT that I’ll sorely miss it).

My options for a new camera body in Spring 2024 are enumerated in the table below:

model price (no VAT)
May 2024
weight with battery EVF IBIS battery
α6100 530 € 396 g poor n NP-FW50
α6400 690 € 404 g ok n NP-FW50
α6500 650 € (used) 453 g ok y NP-FW50
α6600 980 € 503 g ok y NP-FZ100
α6700 1290 € 493 g ok y NP-FZ100

The full frame A7IIc/r camera bodies are very similar to the α6700, but the former in APS-C mode offers a too small resolution, while the latter is way too expensive. Unfortunately Sony seems to not care the lower segment a lot, given that the current Alpha line entry level, the α6100, not only misses IBIS, but also sports the same poor EVF of the α6000, while not being exactly cheap. The α6400 still doesn’t offer IBIS and it’s definitely too expensive. A reasonable option would have been an used α6500, but the only time I tried an used camera didn’t end well and I returned it. The lack of coverage of an inexpensive entry-level body is not only an impression of mine, as it has been recently covered in an interview by the Sigma CEO — the main reason being clearly the strong competition from smartphones, but probably also a lack of creativity in manufacturers.

We’ve seen some cameras with very technically impressive specifications, but I worry that they’re not always capabilities that many photographers really need. Moving forward, I speculate that more user-friendly specifications might mean more to customers. Easier to use interfaces, a compact and lightweight body for enhanced portability, or some other specifications might be more important.

Sony α6700 + Sony FE 200-600mm F5.6-6.3 G OSS @ 433 mm, 1/2000 sec @ ƒ/8, -1.00 EV, ISO 200

Given that there were neither new models announced this year, nor there are rumours about them, in the end I decided for the α6700: definitely expensive, but packed with features, it seemed to me the best investment. It is to be noted, though, the impressive progression in prices in the past ten years — unfortunately there has been also a progression in weights, even though with the α6700 it seems to have been stopped.

model price (no VAT) weight with battery
α6000 370 € (Dec 2014) 344 g
α6300 760 € (Apr 2017) 404 g
α6600 1020 € (Jun 2021) 503 g
α6700 1290 € (May 2024) 493 g

Sony α6700 + Sony FE 200-600mm F5.6-6.3 G OSS @ 415 mm, 1/2000 sec @ ƒ/11, -1.70 EV, ISO 640

Fenicotteri (Phoenicopterus roseus),

Settings

For a general review of how I set my camera bodies, have a look at this old blog post about the α6600 (LINK); here I’m going to update some details.

First, some generic considerations about the news that Sony introduced with the α6700. For what concerns the menus, for sure they have been greatly improved, and now they are pretty good aligned with the ones of full frame cameras (there’s also the capability of saving the whole configuration to a CAMSET file); but the other side of the coin is that, having three cameras bought in a timespan of seven years, I have three very different menu systems (funny enough, phasing out the α6000 I believed I was going to reduce the entropy). Now, fortunately, with a good deal of controls and custom controls the access to the menus can be dramatically reduced, but Sony managed to mess around even here: the REC button has been moved to the top, in the old place of C1, the custom button in the upper back has been removed (summing up, since REC can be customised, we can say that a custom button has been moved to the right side) and the switch that allowed a single button to function as AF/AE-L was removed. Labels are so messed up that the custom button near the “trash” button is labeled in three different ways (C2, C3 and C4) in the three camera models I have. I could mitigate a lot these inconsistencies, but something remains.

As a final note, I welcome the capability of updating the firmware with the SD card; with my other camera bodies, that for this operation need an USB connection and a specific software to run on the laptop, I had problems and in some cases I couldn’t execute the process.

Sony α6700 + Sony FE 200-600mm F5.6-6.3 G OSS @ 200 mm, 1/125 sec @ ƒ/11, -2.00 EV, ISO 50

Oche selvatiche (Anser anser).

As usual I have two memory recalls: MR1 for static subjects and MR2 for fast moving subjects such as birds in flight. In both cases aperture control is primary, so Auto ISO is used; in the latter case it’s also important to have a fixed minimum shutter speed to freeze action. For the α6700 M mode is used because shutter time can be conveniently controlled with the front dial (that cannot be assigned to ISO Auto min. SS); for the α6600, A-mode is still used since there’s no front dial. α6600 introduced “custom hold” settings, which are a subset of overrides that be temporarily activated by pressing a button, eventually also engaging AF: in this way it’s possible to have alternate focusing buttons that also override a few current settings. I programmed Custom Hold 1 to override the focusing area to “Wide focus area”: with the α6600 it’s required by animal eye AF that, unlike human eye AF, doesn’t work with tracking, but only within the active AF area; with the α6700 there’s no such limitation (VERIFY), but the wide focus area can be useful to facilitate the discovery of the subject. Custom Hold 2, instead, activates AF-C and tracking: it can be used for slow moving subjects that alternatively stay put and restart moving (such as critters), without necessarily setting a very fast shutter time as MR2 does; I’ve also noted that AF-C is also dramatically faster and more accurate with a few lenses such as the Sigma 105mm F2.8 DG DN Macro Art. The α6700 introduced a third memory recall, MR3, which I use in a similar way to Custom Recall 2 and additionally setting the AF subject detection to “insects”.

The α6700 introduced a very useful global settings, Full time DMF, that makes it possible to manually override focus in any circumstance, even when the trigger button is not half-pressed.

REMOVE TABLE FROM POST ABOUT a6600, PUT A LINK TO HERE


MR 1
static subjects
MR 2
fast moving subjects
MR 3 (α6700)
insects
Custom hold 1
(α6700, α6600)
tracking
Mode and Aperture A, ƒ/8 M1 (α6700) M
A1, ƒ/8
Shutter speed 1/2000 s 1/1000 s
ISO Auto min. SS Standard3 n.a. in M mode (α6700) Fast
Fast (α6300)3 1/2000 s
ISO2 Auto: 100 — 5000 (α6700)
Auto: 100 — 6400
Metering mode Multi Highlight (α6700)
Multi (α6600, α6300)
Drive mode Brk C 0.3 EV 3 HI HI
Focus mode DMF AF-C AF-C
Focusing area Flexible spot: S Wide
(α6700, α6600)
Wide Tracking: Expand flexible spot
Lock-on AF: Expand flexible spot (α6300)
Subject detection
(α6700, α6600)
Animal/bird (α6700) Bird (α6700) Insects
Human (α6600)4
Face/Eye priority in AF (α6700, α6600) On
1MR2 is set in M mode for a6700 because it’s convenient to control shutter speed with the front dial (it can’t be assigned to ISO auto min. SS); 1/2000 s is preset to freeze birds in flight, the front dial allows to easily lower it for less demanding subjects.
2Maximum values suggested by sensor noise figures — note that the α6700 is more noisy than the predecessors.
3Braver settings could be used, especially with IBIS, but with age my hands are getting more and more shaky.
4It would be nice to have “animal” in MR 2, but the α6600 would disable “Tracking: expand flexible spot” mode. Unfortunately subject detection can’t be overridden by custom holds.

Given these premises I reprogrammed the custom buttons, trying to keep as much consistency as possible with the other two cameras:

  α6700 α6600 α6300
AF/MF n.a. FREE focus mode
AF-ON (α6700)
AEL (α6300, α6600)
autofocus1
⦿ focus standard
focus area
ISO Auto min. SS
Display My Menu3 AF/MF toggle
side

C1 (α6700)
subject detection n.a.
1st top

(α6700)
C1 (α6600, α6300)
focus magnifier
2nd top

C2 (α6700, α6600)
zebra on/off2
upper back

C3 (α6600)
n.a. FREE n.a.
lower back

C3 (α6700)
C4 (α6600)
C2 (α6300)
peaking display peaking level
front dial M mode: shutter speed
Other: ISO
n.a. n.a.
lens custom button recall custom hold 1 (tracking) UNASSIGNED
1It would be nice to assign it to a custom hold which includes AF, as this approach would allow to override a few settings, but in this way it would reset the focusing magnifier.
2Used to quickly declutter the view when composing.
3It’s useless to assign AF/MF toggle for α6700 because it has full time DMF.

Other settings that might be frequently changed have been assigned to the Fn operation menus (TBD ALIGN A6600):

1 2 3 4 5 6
Drive mode Focus mode Steadyshot Metering mode Silent shooting Subject recog. in AF
Aspect ratio ISO DRO Creative style White balance Recognition target
Peaking level (α6300)

Video settings

1 2 3 4 5 6
Audio Rec Level Focus area Steadyshot Steadyshot adj. Silent shooting Metering mode
Zebra level ISO DRO - FOCUS MAP Creative style White balance Subject detection

This outstanding camera body still has its own quirks. For instance:

  1. In spite of having a more recent, back-illuminated sensor with roughly the same number of photosites, the α6700 is consistently ⅓ stop more noisy than its predecessor. Perhaps is a trade-off for the faster sensor readout.
  2. We have yet another Dual ISO sensor with the Auto ISO feature not taking advantage of it. For instance, noise at ISO 400 is lower than in the range ISO 160-250: I'd expect that the sequence of ISO sensibilities picked by the camera would be ISO 100, 125, 400, ..., but there are no gaps in the sequence. Even the α6600 didn't do that, but I expected it was something that the firmware would have picked sooner or later.
  3. When mounting the Sigma 105mm F2.8 DG DN Macro Art with aperture controlled by the lens ring and clicks disabled, if you don't precisely align the aperture ring with the notches the focus assist continuously resets to 1x magnification, as it does when a setting is changed. This is quite funny, because of course the aperture setting doesn't change.

In spite of spending quite a few money for this kind of product, the user manual and the online help are often naive in the description of certain settings. For instance, the description of “Phase Detect. Area” is:

Sets whether or not to display the Phase Detection AF area.
MENU → AFMF (Focus) → [Focus Area] → [Phase Detect. Area] → desired setting.
Menu item details
On:Displays the Phase Detection AF area.
Off:Does not display the Phase Detection AF area.

No figure describing how the area is highlighted (you have to search in third-party web sites to find a few examples), no hint about how the feature could be useful in practice...

NEWS: white balance to daylight, change it at every shot to match what you see. With a6300 it seems to work. New profile v3: 0 EV, unless exceptions contrast: -20 brightness: +20 clarity: +5 structure: +25 sharpening amount: 350 halo suppression: 10 levels min: 0
